SmallHD Cine 5

Name: SmallHD Cine 5
Brand: SmallHD
SKU: 16-0526
Price: 3129.95 AUD
Availability: InStock

$3,129.95 AUD

RRP inc GST /

SKU: 16-0526

For updated Stock on hand, please contact sales@blkflag.com.au otherwise we will email you ETA after confirmed order placement.

Cine 5 is lightweight, compact, and offers 2000nits brightness for full visibility even in direct sunlight. Optional camera-control functionality (software license and cable sold separately) allows users to start, stop, record, and more from the convenience of their Cine 5. Experience all your favorite PageOS 5 tools, functions, and settings pages on this field-ready 5-inch monitor.

1080p resolution ensures a clear look at your production, while 10-bit color processing offers excellent color accuracy. The added joystick and back button allow you to use this smart monitor in nearly all conditions, even on cold days when taking off your gloves is not an option.

Cine 5 is designed for high-end camera use – with bright imagery, optional Camera Control, and 2-pin locking power input – making it ideal field monitor for First ACs, Camera Operators, and DPs.

Camera Control for RED® DSMC2® & RCP2™

Transform your touchscreen into the central command hub of your camera. SmallHD’s proprietary software enables unfettered access to RED DSMC2, KOMODO®, and V-RAPTOR™ camera functions and project settings such as Start/Stop Record, FPS, Shutter Speed, ISO, Color Temperature/White Balance, Clip Playback, and more. *Individual Camera Control software licenses are sold separately.

Additional Camera Control compatibility coming soon.

Item Weight (kg): 0.417
Package Weight (kg): 1.361
Height (cm): 8.6
Width (cm): 13.4
Length/Depth (cm): 3.9
Compliance: FCC, IC, CE, UKCA, RCM, BIS, ROHS
Operating Temperature: 0°C to 41°C
Storage Temperature: -18°C to 49°C
Screen Protection: Clear or Matte
Mount Points: 6x 1/4-20 Mounting Points (3 Bottom, Left, Right, Top)
Construction: Anodized Aluminum unibody
User Function Buttons: Side Joystick Side Back-Button
Panel Type: IPS LCD with touch
Diagonal Size: 4.97"
Resolution: 1920 x 1080
Pixel Density: 443 PPI
Aspect Ratio: 16:9
Active Area: 61.88 x 110.02 mm
Max Brightness: 2000nits
Contrast: 1000:1
Gamut: 97% Rec709
Backlight Type: Edgelit
Refresh Rate: Synchronizes with input from 48Hz to 60Hz
3G-SDI Input Types: 1080p up to 60fps; 1080i up to 120fps · 10-bit
HD-SDI Input Types: 1080p up to 30fps; 1080i up to 60fps; 720p up to 60fps · 10-bit
SD-SDI Input Types: SD up to 59.94fps · 10-bit
HDMI Input Types: 2160p up to 30fps; 1080p up to 120fps · 12-bit
Audio Input Types: HDMI & SDI - Monitor through Speakers in Front Bezel or Through Headphone Jack - Metering up to 8 channels
3G-SDI Output Types: 1080p up to 60fps; 1080i up to 120fps · 10-bit
HD-SDI Output Types: 1080p up to 30fps; 1080i up to 60fps; 720p up to 60fps · 10-bit
SD-SDI Output Types: SD up to 59.94fps · 10-bit
HDMI Output Types: 2160p up to 30fps; 1080p up to 120fps · 12-bit
Audio Output Types: HDMI & SDI - Incoming Audio Stream is sent downstream via HDMI or SDI connection and 1x 3.5mm 3-pin Stereo Headphone
SDI: 1x BNC 3G input and 1x BNC 3G selectable input/output
HDMI: 1 input and 1 output: HDMI Type-A Receptacles (full size)
Audio: HDMI & SDI - Monitor through Headphone Jack - Metering up to 8 channels
Power In: 2-pin Locking
USB: 5-pin locking USB 2.0
Record Capture: Image Capture Tool
Storage Media: 1x SD Card Slot
Input: 2-pin Locking Power Input (10-34V DC, 1.6A)
Pixel Zoom: Yes
Focus Assist: Yes
Peaking: Yes
False Color: Customizable False Color Overlays
Waveform: Customizable 4K Waveform w/Region of Interest Highlighting (Coming Soon)
Custom LUTS: 17pt 3D-LUT on Output/Input 33pt 3D-LUT on Output/Input
Camera Control Compatibility: Camera Control for RED® DSMC2™ Camera Control for RED® RCP2™ Cameras (KOMODO®, DSMC3™) *Additional camera control compatibility coming soon

1 x Cine 5
