Teradek

Teradek Prism 856 Flex II HEVC/AVC 12G-SDI/HDMI En

$6,994.95 AUD
RRP inc GST /
SKU: 10-2856

For updated Stock on hand, please contact sales@blkflag.com.au otherwise we will email you ETA after confirmed order placement.

If you’re looking for a powerhouse encoder that doesn't hog all the space on your desk, the Teradek Prism Flex Mk II is a serious contender. It’s compact enough to tuck away anywhere— whether you’re mounting it right on your camera, sitting it on a tabletop, or squeezing it into your rack between a switcher and a mixer.

What’s really impressive is how it handles connectivity. It has built-in network bonding, meaning you can combine Wi-Fi, Ethernet, and cellular data to make sure your stream stays rock-solid even if one connection dips.

On the technical side, it isn't cutting any corners:

  • Stunning Visuals: It handles up to CI 4K60 video. With 10-bit 4:2:2 color and bitrates climbing as high as 85 Mb/s, your footage stays crisp and professional.
  • Pro Audio: It supports up to eight channels of audio, so your sound remains as high-fidelity as your video.

Essentially, it’s a tiny "set it and forget it" box that ensures your high-res broadcast gets where it needs to go without the usual connectivity headaches.

Video Inputs: 1x 12G/6G/3G/HD/SD-SDI (75 Ω BNC) 1x HDMI 2.0 Type-A receptacle
HDR Support: Yes (2020-PQ, 2020-HLG, P3/D65-PQ)
Video Outputs: 1x 12G/6G/3G/HD/SD-SDI (75 Ω BNC)
Color Sampling: 8-bit, 10-bit encoding Configurable 4:2:2/4:2:0 chroma subsampling
Supported Modes: Single Encode, Bi-directional Encode/Decode (additional license)
Bonding: Up to 5 bonded connections (2x Ethernet, Wi-Fi, internal and external modems)
Supported Resolutions: 4K DCI p23.98/24/25/29.97/30/59.94 4K UHD p23.98/24/25/29.97/30/50/59.94/60 1080p 23.98/24/25/29.97/30/50/59.94/60 1080i 50/59.94/60 1080PsF 23/24/25/29/30 720p 50/59.94/60 576i 480i
Video Compression: ISO MPEG-4 Part 10: Advanced Video Coding (AVC)/ITU H.264 AVC: Baseline, Main, High ISO MPEG-H Part 2: High-Efficiency Video Coding (HEVC)/ITU H.265 HEVC: Main
Supported Video Bitrate: 250 Kbps to 85 Mbps
Video Format Conversion Support: Built in video scaler and deinterlacer
Number of Encoder Streams: Up to one 4KDCI p60 4:2:2 10bit
Network Protocols: TCP/IP, UDP, HTTP, DHCP, NTP, SSL, IGMP
Supported Video Transport Protocols: HLS, MPEG-TS (DASH, UDP, TCP, TCP Server, Multicast), RIST, RTP Push, RTMP / E-RTMP, RTMPS, RTSP, SRT, Teradek Cloud Protocol, Teradek Reliable Transport, WHEP, WHIP
Remote Control: Teradek Core Cloud, Private SDK
Audio Compression: AAC-LC, MPEG Layer II, OPUS, AC3
Supported Audio Bitrate Details: 48kHz
Audio Bitrate: 32kbps to 512kbps
Audio Streaming: 1-8 tracks, configurable mono, stereo, 5.1 or 7.1
IFB: Analog 3.5mm Mic Level, USB-A Headset or Audio Interface (< 1.5A)
Audio Input: 16 channels embedded over SDI, 8 channels over HDMI, 2 channels over 3.5mm TRS Stereo Line Level Analog Input
Audio Output: Analog 3.5mm TRRS headset (Used for IFB)
Dimensions (cm): 0.62”W x 0.36”D x 0.14”H [16.2 x 9.2 x 3.5]
Weight (kg): 0.329
Construction: Milled aluminum
Mountability: Desktop, Four 1/4” 20 threaded mounting holes
Configuration Interfaces: Feature-rich Web UI for local device management, configuration, and control, OLED Status Display w/Nav Control Buttons
Cellular: N/A (supports external modems with USB)
Switches: Menu button and On/Off switch
Recording / Storage: SD Card - Full size, USB Drive, NFS
Cloud Services: Core Cloud, Frame.io, Sony Ci, Sony C3 Portal, PIX, Moxion, Avid
Overlay Engine: Up to 10 Overlays + Additional Dynamic OSD
USB Interface Functionality: 1x Powered 5-Pin Locking Connector with Node Modem support 1x Powered USB-A with Node and external storage support
Ethernet: 2x 10/100/1000 BASE-T Gigabit Ethernet (RJ45)
Wireless: WiFi: 2.4/5GHz 802.11 a/b/g/n/ac/ax MIMO - BLE for Network Configuration
Power Input: 2-pin circular locking connector
Nominal Power Consumption: 20W Nominal, 36W Max
1 x Prism Flex Mk II Encoder
1 x Ethernet Cable
1 x HDIM Male to HDMI Male Cable (18 in)
1 x SDI 12G BNC to BNC Cable (18 in)
1 x PSU 2pin Conn. to 26W AC Adapter (6 ft)
2 x Antenna 2dBi WIFI 2.4/5.8 GHZ
