Anton Bauer

Anton Bauer VCLX NM2, Charger and 4 foot charger cable package

$9,299.95 AUD
RRP inc GST /
SKU: 8275-0155

For updated Stock on hand, please contact sales@blkflag.com.au otherwise we will email you ETA after confirmed order placement.

The short version: the VCLX NM2 600Wh block battery, its charger and the 48 inch charge cable in one package.

What you'd use it for

The VCLX NM2 is the classic Anton/Bauer block battery: a 600Wh NiMH box that sits on the floor or a cart and runs high current gear by cable. It puts out 14.4V on two 4 pin XLR connectors and 28V or 48V on one 3 pin XLR, both at the same time, so a camera and a big light can share the one battery.

On the matching VCLX 2 charger it charges faster than any other block battery on the market, according to Anton/Bauer. Battery ID, learned capacity, cycle count and time stamped errors show on the unit or through Fleet Management over the built in Wi-Fi.

In real world terms

  • How much power? 600Wh, NiMH chemistry.
  • Outputs? Two 4 pin XLR at 14.4V plus one 3 pin XLR at 28V or 48V, running at the same time.
  • What's left? A 2.4 inch LCD shows remaining capacity at all times.
  • Protection? Smart electronic fuses warn you on the screen and reset themselves once it is safe. It also shuts itself off at 12V so the cells are not damaged.
  • Max load? 700W.

Good to know

  • Two year warranty.

Works with

Keep it secure on set with the VCLX Caddy.

What's in the box

  • 1 x VCLX NM2
  • 1 x VCLX NM2 charger
  • 1 x VCLX NM2 48 inch charging cable
Capacity: 600 Wh
Voltage: Multi
Chemistry: Nickel Metal Hydride
Power Tap: No
USB: Yes
XLR Inputs: Yes
XLR Connector: Yes
Width: 33 cm
Height: 25.5 cm
Depth: 15.3 cm
Weight: 1.33 kg
Warranty: 2 years
Built-In Discharge: No
Battery Max Load: 700W
Camera Interface: 2 X 4-Pin XLR (14.4v), 1 X 3-Pin XLR (28v or 48V)
1 X VCLX NM2
1 X VCLX NM2 Charger
1 X VCLX NM2 48″ Charging Cable
