Sachtler aktiv8 flowtech75 System Kits

$7,499.95 AUD

RRP inc GST /

SKU: S2068S-FTMSSKU: S2068S-FTGSSKU: S2068T-FTMSSKU: S2068T-FTGS

Select an option to add this to your cart.

Camera plate : Sideload : Touch & Go

Spreader : Mid level : Ground

For updated Stock on hand, please contact sales@blkflag.com.au otherwise we will email you ETA after confirmed order placement.

What you'd use it for

The aktiv8 flowtech75 system is both lightweight and durable, designed to be a long-serving and high-performing part of your kit. This system is the perfect choice for professional medium-sized camcorders and digital cine camera set ups of up to 12 kg (26.5 lbs.). 15 counterbalance steps allow for fast and precise balancing of your camera. Seven drag settings provide smooth and fast options to adjust drag performance without jolts or vibrations. The illuminated PrismBubble with top or side view makes levelling easy from any height.

The same head is offered with a choice of two camera plate systems, and that choice is what the Camera plate selector sets. The aktiv8 carries the Sideload mechanism, part numbers S2068S-FTGS and S2068S-FTMS. The aktiv8T carries the Touch & Go camera platform in place of the Sideload mechanism, part numbers S2068T-FTGS and S2068T-FTMS. Payload, counterbalance steps, drag settings and levelling are the same on both, and BFD prices them the same.

Technical data

Fluid head, Sideload	Sachtler aktiv8 with Sideload
Fluid head, Touch & Go	Sachtler aktiv8T with Touch & Go
Tripod	flowtech75
Payload	Up to 12 kg (26.5 lbs.)
Counterbalance steps	15
Drag settings	Seven
Sliding range, Sideload	120 mm
Sliding range, Touch & Go	Not stated in Sachtler's published aktiv8T data
Levelling	Illuminated PrismBubble, top or side view
Sideload, ground spreader system	aktiv8 fluid head, flowtech75 tripod, ground spreader. System weight 6.5 kg (14.3 lbs.)
Sideload, mid level spreader system	aktiv8 fluid head, flowtech75 tripod, mid-level spreader. System weight 6.3 kg (13.9 lbs.)
Touch & Go, ground spreader system	aktiv8T fluid head, flowtech75 tripod, ground spreader. System weight 6.6 kg (14.5 lbs.)
Touch & Go, mid level spreader system	aktiv8T fluid head, flowtech75 tripod, mid-level spreader. System weight 6.4 kg (14.1 lbs.)
Part numbers	aktiv8 Sideload: S2068S-FTGS (ground), S2068S-FTMS (mid level). aktiv8T Touch & Go: S2068T-FTGS (ground), S2068T-FTMS (mid level)

Options

Camera plate

Sideload is the mechanism fitted to the aktiv8. The camera loads from the side onto a sliding platform and moves fore and aft over a sliding range of 120 mm, the longer travel of the two, so it suits a rig whose balance point moves as the configuration changes. Part numbers S2068S-FTGS and S2068S-FTMS.

Touch & Go is the camera platform fitted to the aktiv8T in place of the Sideload mechanism. The camera drops onto the plate from above into a preset position and comes on and off one handed, so it suits a crew mounting the same camera on the head again and again. Part numbers S2068T-FTGS and S2068T-FTMS. Sachtler does not publish a sliding range figure for the aktiv8T.

Spreader

Ground and mid level spreaders are offered against both camera plates, on the same flowtech75 tripod and at the same price. With the Sideload plate the ground spreader system weighs 6.5 kg (14.3 lbs.) and the mid level system 6.3 kg (13.9 lbs.). With the Touch & Go plate the ground spreader system weighs 6.6 kg (14.5 lbs.) and the mid level system 6.4 kg (14.1 lbs.).

Figures published by Sachtler.

Payload @ 100mm cog: 0 kg to 12 kg
Drag: 7 + 0 drag settings
Counterbalance: 15 + 0 counterbalance steps
Bowl Size: 75 mm
Height With Ground Spreader: 56 cm to 176 cm
Height Without Spreader: 23 cm to 170 cm
Material: Carbon Fibre
Tripod Stages: 2
Spreader Type: Ground spreader
Weight: 6.5 kg
Transport Length: 85 cm
Interface Compatibility: Sideload
Pan Bar Count: 1
Tilt Range: 90° to -70°
Sliding Range: 12 cm
Temperature Range: -40°C to 60°C
Fluid Head: aktiv8

aktiv8 (S2068S)
Tripod flowtech® 75 aktiv GS (4587)
Padded bag flowtech®75 (9116)
Carry handle flowtech, rotating (S2051-1062)
