SmallHD

SmallHD Cine 13" 4K High-Bright Monitor

$9,489.95 AUD
RRP inc GST /
SKU: MON-CINE-13

For updated Stock on hand, please contact sales@blkflag.com.au otherwise we will email you ETA after confirmed order placement.

Cine 13 is an agile, brilliantly bright, and pixel-dense 4K production monitor designed for those on-set creatives who require critical focusing capability and a large display. Low-profile in design, this field companion can be rigged for almost any situation. And, weighing in at only 6.8lbs, the Cine 13 is making monitoring in 4K more portable than ever.

The Cine 13” 4K High-Bright Monitor boasts over 1500nits of brightness, ensuring an unobstructed look at your production in full sunlight without the need for a sunhood or viewing tent. The 13-inch screen has a 3840 x 2160 resolution and full 4K clarity, as well as 10-bit color depth for color-accurate images.

Cine 13 features four 12G SDI inputs and outputs as well as one HDMI 2.0 input. The Unibody Smart Chassis offers an Arca Slide on Rail for battery and accessory mounting, a lower mounting rail for ultimate flexibility, and 2x 2-pin accessory power outputs. Hot-swappable dual inputs allow you to add on Gold Mount or V-Mount battery plate attachments.

Meet Our Smart PageOS Software

With the power of SmallHD PageOS software, build customized Page Profiles, and utilize all of the dependable SmallHD features such as personalized frame guides, Focus & Exposure Assist, high-resolution 3D LUT overlays, histogram, vectorscope, waveform, and more. Learn more about PageOS.

Item Weight (kg): 3.09
Package Weight (kg): 7.257
Height (cm): 25.7 w/o feet and handle, 31.6 w/ feet and handle
Width (cm): 33.7
Length/Depth (cm): 6.1 w/o feet, 12 w/feet
Compliance: FCC, IC, CE, UKCA, BIS, RCM, ROHS
Operating Temperature: 0°C to 41°C
Storage Temperature: -18°C to 49°C
Screen Protection: Hardened
Mount Points: Interchangeable accessory mount plates on top and sides with multiple ¼”-20 and/or ⅜”-16 options
Construction: Anodized Aluminum unibody
Panel Type: IPS LCD
Diagonal Size: 13.3"
Resolution: 3840x2160
Pixel Density: 332 PPI
Aspect Ratio: 16:9
Active Area: 293.76 (H) x 165.24 (V) mm
Max Brightness: 1500nits
Contrast: 1300:1
Gamut: 99% Rec709
Color Depth: 10-bit (8+2)
Backlight Type: Edgelit
Refresh Rate: Synchronizes with input from 48Hz to 60Hz
Display Size: 13"
Panel Resolution: 3840 x 2160
Color Bit Depth: 10-bit (8+2)
3G-SDI Input Types: DCI-2K up to 30fps; 1080p up to 60fps · 12-bit
6G-SDI Input Types: DCI-4K up to 30fps; 2160p up to 30fps; DCI-2K up to 60fps; 1080p up to 60fps · 12-bit
12G-SDI Input Types: DCI-4K up to 60fps; 2160p up to 60fps · 12-bit
HD-SDI Input Types: 1080p up to 30fps; 1080i up to 60fps; 720p up to 60fps · 10-bit
SD-SDI Input Types: SD up to 59.94fps · 10-bit
HDMI Input Types: DCI-4K up to 60fps; 2160p up to 60fps; DCI-2K up to 60fps; 1080p up to 60fps · 12-bit
Audio Input Types: HDMI & SDI - Monitor through Speakers in Front Bezel or Through Headphone Jack - Metering up to 8 channels
3G-SDI Output Types: DCI-2K up to 30fps; 1080p up to 60fps · 12-bit
6G-SDI Output Types: DCI-4K up to 30fps; 2160p up to 30fps; DCI-2K up to 60fps; 1080p up to 60fps · 12-bit
12G-SDI Output Types: DCI-4K up to 60fps; 2160p up to 60fps · 12-bit
HD-SDI Output Types: 1080p up to 30fps; 1080i up to 60fps; 720p up to 60fps · 10-bit
SD-SDI Output Types: SD up to 59.94fps · 10-bit
HDMI Output Types: DCI-4K up to 60fps; 2160p up to 60fps; DCI-2K up to 60fps; 1080p up to 60fps · 12-bit
Audio Output Types: 1x 3.5mm 3-pin Stereo Headphone Jack and built in speaker
SDI: 4x BNC 12G input and 4x BNC 12G output
HDMI: 1 input and 1 output: HDMI Type-A Receptacles (full size)
Audio: HDMI & SDI - Monitor through Speakers in Front Bezel or Through Headphone Jack - Metering up to 8 channels
Power In: 4-pin XLR
Power Out: 2x 2-pin locking (12VDC @ 2A Max), 1 USB type C (5V @ 1.5A max)
USB: 2x USB A, 1x USB C
Primary: RJ45 for GPI
Record Capture: Image Capture Tool
Wireless: 2.4GHz WLAN
Connector Type: 1x SD Card Slot, 1x RJ45 Ethernet, 1x RJ45 GPI
Audio: 1x 3.5mm 3-pin Stereo Headphone Jack
Ethernet: RJ45
Storage Media: 1x SD Card Slot
WiFi: 2.4GHz WLAN
Input: 1x XLR 4-pin 12 - 34VDC IN (210W max, 12V-34V, 18A max)
Output: 2x 2pin (12V / 2A combined), 1x USB-A (2.4A) (Front), 1x USB-A (1.5A) (Rear), 1x USB-C (5V / 1.5A) (Rear)
Consumption: 36.7w (monitor only) 117.9w (w/max access. power draw)
Battery Plate Included: No
Battery Types: 1x Dual-GM/VM Batt.Plate (14/26V) (sold as accessory)
1 x SmallHD 4K Monitor Feet (Set)
1x 8GB SD Card
1x SmallHD Cleaning Cloth
1x 24V Power Supply
1x Mounting Rail for Cine 13
1x Premium Monitor Handle for 4K Monitors
1x Cine 13 Transport Screen Protector
