SmallHD OLED 16 4K Production Monitor

Name: SmallHD OLED 16 4K Production Monitor
Brand: SmallHD
SKU: 16-1601
Price: 11384.95 AUD
Availability: InStock

$11,384.95 AUD

RRP inc GST /

SKU: 16-1601

For updated Stock on hand, please contact sales@blkflag.com.au otherwise we will email you ETA after confirmed order placement.

OLED 16 is a 16-inch reference-grade production monitor built for precise color evaluation and consistent image matching across multi-monitor workflows. Designed for on-set and studio use, it delivers true blacks and stable color performance in a compact form factor ideal for DIT carts and video village.

Featuring a 3840 × 2400 panel with 10-bit processing and a 1,000,000:1 contrast ratio, OLED 16 supports four 12G inputs and outputs. The unibody chassis provides flexible mounting and a smart rail system for fast rigging and expansion.

Running PageOS, OLED 16 integrates seamlessly into larger monitor ecosystems. With built-in WiFi and Fleet Control support, users can deploy settings, LUTs, and configurations across multiple monitors to maintain consistency on set. Four front-facing customizable dials provide fast, tactile control for critical adjustments.

Self-emissive OLED technology ensures accurate shadow detail and exposure evaluation without blooming or haloing, making OLED 16 well-suited for high-end cinematography and client-facing review environments where image consistency matters.

Key Features

16" Rugged, Set-Ready Chassis
100% DCI-P3, 80% Rec.2020
Up to 400nits
3840 x 2400 Resolution
4x 12G-SDI In/Out; 1x HDMI 2.0
4x Multi-Function Dials; WiFi

Specifications

Panel Type	AMOLED
Diagonal Size	16"
Resolution	3840 x 2400
Max Brightness	400nits
Contrast	1,000,000:1
Gamut	100% Rec709, 100% DCI-P3, 80% Rec2020
Color Depth	10-bit
Refresh Rate	Fixed 60Hz
Video I/O	4x 12G-SDI In, 4x 12G-SDI Out, 1x HDMI 2.0
Audio Output	1x 3.5mm
Data I/O	1x RJ45 Ethernet, 1x RJ45 GPI, 1x USB Front, 2x USB Rear
Power Input	1x 4-pin XLR (12V to 34V DC, 143W max); dual Gold Mount / V-Mount battery plate (14V/26V) sold separately
Power Output	2x 2-pin locking, 1x USB (5V/2.4A) Front, 2x USB (5V/1.5A) Rear
Weight	4.72 kg (10.4 lb)
Height	31.2 cm without feet and handle, 36.1 cm with feet and handle
Width	40.1 cm (15.8")
Depth	6.9 cm without feet and handle, 11.9 cm with feet and handle
Operating Temperature	0°C to 40°C (32°F to 105°F)
Compliance	FCC, IC, CE, UKCA, RCM, ROHS
