SmallHD Ultra 10 Bolt 6 RX

$11,384.95 AUD - $13,284.95 AUD

RRP inc GST /

SKU: 16-1002-GMSKU: 16-1002-VMSKU: 16-1003-GMSKU: 16-1003-VM

Select an option to add this to your cart.

Configuration : 750 ft / Gold Mount : 750 ft / V-Mount : 1500 ft / Gold Mount : 1500 ft / V-Mount

For updated Stock on hand, please contact sales@blkflag.com.au otherwise we will email you ETA after confirmed order placement.

Ultra 10 strikes the perfect balance between screen size and lightweight portability with a feature-packed 10-inch Ultra-Bright Monitor designed to adapt to any production scenario. Key features include 2000 nits of brightness, 6G-SDI architecture, an impact-resistant IP54-certified form factor, and more ways than ever to customize your PageOS workflow via touchscreen, joystick, large tactile buttons, and new multi-function rotary encoder knobs for maximum control in all conditions.

The Ultra 10 Bolt 6 RX features an integrated Teradek Bolt 6 Receiver, allowing you to receive zero-delay wireless video from your camera via the new internal V-Antenna at ranges up to 750 or 1500 feet. It is available as a Gold Mount or V-Mount option.

Ultra 10 is our first IP54-certified monitor, which is defined as resistant to water spray from any direction and protection against dust and dirt in extreme environments while operating in variable temperatures ranging from 0ºC to 40ºC. The chassis features raised edges protecting the front glass of the display and user-replaceable shock-absorbing bumpers to mitigate drops, tumbles, and impacts

Ultra 10 comes with 5-pin locking USB and Ethernet ports for optional ARRI, Sony VENICE, BURANO and FX6, and RED® Camera Control (license and cable sold separately).

IP Rating: IP54
Package Weight (kg): 4.082
Height (cm): 22.8
Width (cm): 25.4
Length/Depth (cm): 5.6 w/o Gold Mount
Compliance: FCC, IC, CE, UKCA, MIC, RCM, ROHS
Operating Temperature: 0°C to 41°C
Storage Temperature: -18°C to 49°C
Screen Protection: Clear or Matte
Mount Points: 11x 1/4-20 Mounting Points (9 Top, Left, Right), 1x 3/8, 1 Arca Rail
Construction: Anodized Aluminum unibody with plastic accents
Panel Type: IPS LCD with touch
Diagonal Size: 10.1"
Resolution: 1920x1200
Pixel Density: 224 PPI
Aspect Ratio: 16:10
Active Area: 135.36(H) x 216.58(V) mm
Contrast: 1000:1
Gamut: 99.8% Rec709
Color Depth: 10-bit Processing (8-bit panel)
Backlight Type: LED Edgelit
Refresh Rate: Synchronizes with input from 48Hz to 60Hz
3G-SDI Input Types: 1080p up to 60fps; 1080i up to 120fps · 10-bit
6G-SDI Input Types: DCI-4K up to 30fps; 2160p up to 30fps; DCI-2K up to 60fps; 1080p up to 60fps · 12-bit
HD-SDI Input Types: 1080p up to 30fps; 1080i up to 60fps; 720p up to 60fps · 10-bit
SD-SDI Input Types: SD up to 59.94fps · 10-bit
HDMI Input Types: 1080p up to 60fps · 12-bit
Audio Input Types: HDMI & SDI - Monitor through Speakers in Front Bezel or Through Headphone Jack - Metering up to 8 channels
3G-SDI Output Types: 1080p up to 60fps; 1080i up to 120fps · 10-bit
HD-SDI Output Types: 1080p up to 30fps; 1080i up to 60fps; 720p up to 60fps · 10-bit
SD-SDI Output Types: SD up to 59.94fps · 10-bit
HDMI Output Types: 2160p up to 30fps; 1080p up to 120fps · 12-bit
Audio Output Types: HDMI & SDI - Incoming Audio Stream is sent downstream via HDMI or SDI connection and 1x 3.5mm 3-pin Stereo Headphone
SDI: 1x BNC 6G input and 1x BNC 6G selectable input/output
HDMI: 1 input and 1 output: HDMI Type-A Receptacles (full size)
Audio: HDMI & SDI - Monitor through Headphone Jack - Metering up to 8 channels
Power In: Rear Battery Plate Interface Optional V-Mount, Gold-Mount, or B-Mount Wooden Camera Mico Battery Plate (10V - 34V) 2-Pin Locking (10V - 34V)
Power Out: 2-Pin Locking Power Passthrough Output
USB: 5-pin locking USB 2.0
Primary: RJ45 for GPI
Record Capture: Image Capture Tool
Wireless: 2.4GHz WLAN
Ethernet: RJ45 and GPI
Storage Media: 1x SD Card Slot
WiFi: 2.4GHz WLAN
Monitoring I/O: SDI: 1x BNC 12G input and 1x BNC 12G selectable input/output HDMI: 1 input and 1 output: HDMI Type-A Receptacles (full size) Audio: 1x 3.5mm 3-pin Stereo Headphone Jack Ethernet: RJ45 and GPI
Connector: 2-Pin Locking Connector
Voltage: DC in - 10V minimum to 34V maximum, Battery terminals - 6.0V minimum to 16.8V max
Power Supply: Recommend DC 12~15V at ~2.5 amp or greater
Battery Types: V Mount, Gold Mount Micro Battery Plates
Overload Protection: DC input: Reverse polarity
Battery Chemistry: Li-ion
Pixel Zoom: 1.1-2.0x & 2.0-8.0x via swipe up/down. Infinitely adjustable via pinch & zoom
Frame Guides: Preset Aspect Ratios & Customizable
DSLR Scale: Canon 5DMkii & Canon 7D
Custom Scale: Yes (Underscan Only)
Anamorphic De-Squeeze: 0.75x, 1.33x, 1.5x, 1.66x, 2.0x, 2.5x
Image Rotate: Automatic or Manual Control
Image Flip: Automatic or Manual Control
Cross Conversion: Yes: HDMI → SDI & SDI → HDMI
Focus Assist: User Adjustable Color Style and Intensity
Peaking: User Adjustable Intensity
False Color: Rainbow, Arri Style, Custom with up to 10 nodes
Zebra: Dual - User Configurable
Waveform: Luma & RGB Style, Fully User Customizable w/ Region of Interest Highlighting
Vectorscope: Yes
RGB Parade: Fully User Customizable
Histogram: Luma & RGB Style
Image Capture: Yes
LUTS: - 33pt User LUT instead of 17pt - 33pt Cal LUT instead of 17pt - LUT tool continues to work after removable media containing the LUT has been removed
Custom LUTS: - Loadable as Looks on Pages or as Systemwide Color Calibration via the settings menu - LUT Downstream: Available on SDI or HDMI Out. Applied on Output Preview Page. - LUT Import: via SD Card or USB Storage Device
Color Pipe: - Unique Calibrations may be saved to each Color Pipe - Accurate color processing
Overlay: With Opacity Slider and Blink Setting
Audio Meters: HDMI & SDI up to 8 channel
Multi-View: 2 camera feeds simultaneously

1x Ultra 10 Bolt 6 RX
1x D-Tap to 2-Pin Power Cable – 36in
1x Micro Battery Plate – Ultra Series
1x Ultra 10 Bolt 6 Color Bands
1x Monitor Handles Neck Strap
1x Ultra Screen Protector for Ultra 10
1x 8GB SD Card
1x SmallHD Cleaning Cloth
