Teradek RT MDR.S Receiver

$1,829.95 AUD
RRP inc GST /
SKU: 15-0049

For updated Stock on hand, please contact sales@blkflag.com.au otherwise we will email you ETA after confirmed order placement.

The RT MDR.S Compact Three Axis Lens Control Receiver w/ Bluetooth offers premium lens control at a reasonable price. It is our affordable and compact receiver for lens focus, iris, and zoom control with Teradek RT. This small but robust receiver weighs only 2.4 oz. – 30% smaller than its predecessor, MDR.X – making it simple to add to any smaller camera, drone, or gimbal without overcrowding or weighing down. MDR.S allows for up to 3 channels of lens control, with the ability to daisy-chain up to 3 motors for a cleaner build. The camera control port allows users to start and stop recording from your RT hand unit. The power port supports up to 28V for compatibility with a wide range of cameras.

The MDR.S receiver features FHSS wireless technology – which prevents interference – an OLED screen with a simple menu system, a replaceable and customizable external antenna, and maximum line-of-sight range of 5,000 ft. Using the MDR.S’s integrated Bluetooth, you can remotely control your lens with the Teradek RT app for iOS.

MDR.S is compatible with MOTR.S, MOTR.S MAX, MOTR.X, MK3.1 motors, wired controllers, CTRL.5, CTRL.1, CTRL.3. This three-motor receiver can be bundled with our RT FIZ Kit and Single Channel Wireless Control Kit to give you complete lens control for focus, iris, and/or zoom.

Front Panel Interface: OLED Screen with menu system and button navigation
Camera Control Support: RED DSMC2, RED DSMC control: EF/AF Focus/Iris, Shutter, ISO Button features: 2x Magnification, Edge, Focus Assist
Desktop App: Teradek RT Settings Manager, Teradek RT Firmware Configuration App
Bluetooth: CTRL.3 MDR.ACI RT App
Power Input: 3-Pin LEMO 0B 5-28 VDC
Wireless: Teradek RT FHSS: 2.4GHz Bluetooth: 2.4GHz
Wireless Range: Up to 5000 ft (1500 m) line-of-sight (in USA/FCC mode), Up to 500 ft (150 m) indoors
Latency: 2 ms
Operating Temperature: Operating: -4 to 122ºF (-20 to 50ºC)
Storage Temperature Range: Storage: -40 to 85°C (-40 to 85ºC)
Certifications: -
Mountability: 1/4-20 mounting thread
Dimensions (cm): 0.23”W x 0.17”D x 0.09”H [5.79 x 4.2 x 2.4]
Weight (kg): 0.068
Construction: Milled Aluminum 6061 --T6 (Chassis) and regulation-compliant PCB
Power Input: 3-pin LEMO 0B (5-28V)
Camera Input (CAM): 6-pin LEMO 0B RS-232 for RED control Programmable line driver for select cameras
Motor Inputs: 4-pin LEMO 0B
USB-C Input: Firmware upgrade
RF Handset Support: Teradek RT CTRL.1 Controller Teradek RT CTRL.3 Controller Teradek RT MK3.1 Controller
Camera Run/Stop Support: RED (Epic, Scarlet, Weapon, Raven, etc.) ARRI (Alexa, Amira, etc.) Phantom Sony F55 LANC (Blackmagic, Canon C100/300/500 Sony FS7)
Teradek RT Accessory Support: MOTR.X MK3.1 Motor Thumbwheel Latitude Receivers MK3.1 Receiver
App Support: Teradek RT iOS App, FoolControl for iOS devices
1 x MDR.S
1 x USB 2.0 Type A Male to USB Type C Male - 1m Cable
1 x Teradek RT Power 3 pin - P Tap Cable
1 x Antenna Straight WiFi 2.4GHz 28.4mm length 0.56db rp-sma
1 x MDR.S Bracket
1 x Screw Socket Head Black M2 x 6mm
1 x Screw Socket Cap 1/4-20 x 3/8in
