How to Design a Photo and Video Studio with Litepanels: Gemini, Astra IP and Combined Builds

Building a photo and video studio around Litepanels comes down to three honest choices: the colour-rich Gemini RGBWW soft panels, the weatherproof, value-focused Astra IP bi-color range, or a combination of both matched to your budget and the look you want. This guide walks through all three builds, the accessories that make them sing, real studio layouts, and genuine case studies so you can plan a room that works on day one and still holds up in five years.

Why build a studio around Litepanels

Litepanels is a broadcast lighting brand under the Videndum group, and its panels are built for the two things a permanent studio needs most: colour accuracy that stays put and control that scales. A studio light is on for hours a day, in front of a locked-off camera, often mixed with daylight from windows or LED walls. That is a very different job to a run-and-gun on-camera light, and it is where these fixtures earn their place.

Two families do most of the work in a studio. The Gemini panels are full-colour RGBWW soft and hard lights aimed at creative control, gels and effects. The Astra IP panels are rugged, weatherproof bi-color workhorses aimed at value and reliability. You can build a great studio from either one alone, and an even better one by combining them. Below, each build is laid out with the exact fixtures, the accessories, an example layout, and roughly what the fixtures cost at listed Australian prices.

A note on pricing: the figures below are indicative Australian recommended retail prices at the time of writing and are there to help you scope a budget. Prices and stock change, so confirm current pricing with your nearest stockist before you commit. I have flagged specifications drawn from Litepanels' published data and linked the sources so you can verify them yourself.

Build 1: The Gemini soft build (colour and creative control)

This is the build for a studio that shoots portraits, fashion, music content, interviews with a designed backdrop, or anything where colour and mood are part of the brief. The Gemini 2x1 Soft and Gemini 1x1 Soft are RGBWW panels, meaning they mix red, green, blue and two shades of white to hit an enormous colour range as well as clean, accurate white light.

Gemini soft specifications

Specifications above are from Litepanels' Gemini 2x1 Soft product page. The 1x1 Soft shares the same colour engine in a smaller, lighter body.

Why it works in a studio

The soft panels have a large, even emitting surface, so out of the box they give you a flattering wrap without a modifier. The CRI 99 and TLCI 99 figures mean skin tones and brand colours render honestly on camera, and because it is a true RGBWW engine you can dial an exact gel colour for a backdrop and save it as a preset. The onboard 300-gel library means you can match a specific LEE or Rosco number your gaffer already trusts, and the effects engine covers everything from a warm candle flicker to a TV-glow wash without extra hardware.

Recommended accessories for the Gemini build

• Snapbag Softbox for Gemini 1x1: adds even more wrap for beauty and interview keys.
• Snapgrid 40 degree eggcrate: controls spill and stops light hitting the backdrop when you want separation.
• 4-way barn doors: fast, tactile flagging on the fixture itself.
• Gemini 1x1 Intensifier: narrows the beam and boosts punch when you need more throw or a harder edge.
• Dual Gemini 1x1 array kit with yoke: gang two 1x1 panels into a taller source for full-length portrait keys.
• Wireless DMX module: bring every fixture under one console or app with no cable runs across the floor.
• Hard case for Gemini 1x1: protects the investment if fixtures ever leave the studio.

Example layout: a portrait and interview studio

A clean three-source setup that suits headshots, talking-head interviews and social content:

• Key: one Gemini 2x1 Soft at 45 degrees to the subject, fitted with a snapgrid to keep light off the backdrop.
• Fill: one Gemini 1x1 Soft on the opposite side at low intensity, or bounced, to open the shadows.
• Hair and separation: a second Gemini 1x1 Soft from behind and above with barn doors.
• Backdrop colour: a third 1x1 Soft set to an RGBWW colour to paint the background, giving you brand-matched separation without a gel change.

Indicative fixture cost: roughly $13,000 to $16,000 for the four panels at listed prices, before modifiers and stands.

Build 2: The Astra IP build (value, reliability and mixed use)

This is the build for a studio that needs dependable, accurate light without the full colour engine, or that doubles as a space for corporate video, education, live streaming and product work. The Astra IP range is bi-color, so it adjusts between warm and cool white rather than full RGB, and it is IP65 rated, which means it shrugs off dust and water. That matters even indoors: a weatherproof fixture is a fixture that survives a leaky roof, a haze machine, an outdoor pickup shot, or a decade of studio dust.

Astra IP specifications

Specifications above are from Litepanels' Astra IP product page. Litepanels does not publish a CRI figure on that page, so I have left it out rather than quote a number I cannot verify; the range is marketed on accurate colour with no shift across intensity.

Why it works in a studio

Astra IP gives you three sizes that step up cleanly in output, so you can right-size the fixture to the job: a Half as a hair light, a 1x1 as a fill or key, a 2x1 as a soft key or backdrop wash. The bi-color engine holds its colour as you dim, which keeps a multi-camera set matched. Because the fixtures are weatherproof and physically tough, an Astra IP room is close to future-proof. Litepanels also sells these as ready-made kits, which is the fastest way to stand up a room: the Astra IP Half Duo kit and the Astra IP 1x1 Trio kit arrive cased with yokes and cables.

Recommended accessories for the Astra IP build

• Astra IP Half Snapbag Softbox and 2x1 Snapbag Softbox: instant soft key from a hard-ish panel.
• Snapgrid direct-fit eggcrate: tightens control for backgrounds and edges.
• 4-way barn doors, Astra direct fit: quick flagging on the fixture.
• DMX module for Astra IP: puts the whole rig on a lighting desk for repeatable, saved states.
• V-mount battery bracket: run a fixture off battery for a location day or an untethered corner of the studio.

Example layout: a multi-use corporate and streaming studio

• Key: Astra IP 2x1 in a snapbag, camera left, as a broad soft key.
• Fill: Astra IP 1x1 camera right at low level.
• Hair or rim: Astra IP Half with a snapgrid from behind.
• Background: a second Astra IP 1x1 grazing the backdrop or a set wall.

Indicative fixture cost: roughly $11,000 to $13,000 for the four panels at listed prices, or step into a cased 1x1 Trio kit at around $12,600 for a turnkey three-light package.

Build 3: The combined build, by price point

The best studios usually mix both families: Astra IP as the dependable, always-on workhorses, and a Gemini or two where you need colour, effects or the softest possible key. Here is how that plays out at three budgets. Treat these as starting points for the fixtures themselves; add stands, modifiers and cabling to suit.

Entry studio (around $8,000 to $10,000 in fixtures)

This gives a solo creator or small business a colour-capable key and two reliable support lights.

Mid studio (around $14,000 to $18,000 in fixtures)

This is the sweet spot for a busy commercial studio: creative colour where it counts, value where it does not.

Premium studio (around $25,000 and up in fixtures)

Put the whole rig on wireless DMX with the Gemini wireless DMX module and matching Astra IP modules, and every scene becomes a saved, recallable preset.

Accessories that turn panels into a studio

Fixtures make light; accessories shape it. A studio lives or dies on modifiers, so budget for them from the start rather than as an afterthought. The essentials, all available for these panels:

• Softboxes: the Gemini Snapbag and Astra IP Snapbag ranges give you the biggest, softest wrap for beauty and interviews.
• Eggcrates and grids: snapgrids for Gemini and Astra IP stop light spilling onto backdrops and lenses.
• Barn doors: tactile flagging on the fixture for Gemini and Astra IP.
• Intensifiers and diffusers: the Gemini Intensifier hardens and boosts throw; the diffuser panels soften further.
• Arrays and yokes: the dual 1x1 array kit builds a taller, larger source from two panels.
• Control and power: wireless DMX, Astra IP DMX modules and battery brackets for untethered fixtures.
• Cases: road cases and hard cases protect fixtures that travel.

Cost savings: LED versus traditional studio lighting

One of the strongest reasons to build a studio on LED fixtures is running cost. Traditional tungsten and HMI studio lights draw a lot of power, throw off a lot of heat that then loads your air-conditioning, and burn through replacement lamps. Modern LED fixtures like the Gemini and Astra IP ranges do the same lighting job for a fraction of the power and with almost no lamp-replacement cost, which adds up quickly in a room that runs every day.

A published Litepanels case study puts real numbers on it. The production company Plaid Turtle replaced more than 70 traditional lighting fixtures with just 20 Gemini 1x1 Hard panels, and in doing so cut the power their shoots drew from more than 70,000 watts to about 4,000 watts. That is roughly a 94 percent reduction in power draw, calculated from the wattage figures Litepanels publishes, and the company reports its operating costs dropped sharply as a result. The team described the panels as "so bright and yet feel so comfortable" to work under. Read the full Plaid Turtle case study.

A note on the figures: Litepanels describes the operating-cost saving as significant but does not publish a dollar amount, so I have not invented one. The 94 percent figure is derived from the published before-and-after wattage. Your own saving depends on your electricity tariff, how many hours you shoot, and what you are replacing, so treat this as an indicative example rather than a promise.

Real-world proof: studios that run on these lights

These are genuine, published Litepanels case studies, linked so you can read them in full.

CNN London

CNN's London bureau rebuilt its lighting around Gemini panels: Gemini 2x1 Soft fixtures light the main studio and video walls, while compact Gemini 1x1 fixtures handle a set of smaller self-operated studios where space is tight and there is no dedicated lighting crew on hand. It is a clear example of soft panels doing both the hero work and the everyday work in one facility. Read the full CNN London case study.

Product and tabletop: the Ciroc shoot

For a Ciroc product shoot, the Andrew Kung Group lit bottle and pour work with four Gemini 2x1 panels, shooting slow motion at high frame rates. The team described the panels as "consistent and flicker-free at any intensity, frame rate and shutter angle," which is exactly the quality that matters for high-speed and tabletop work. Read the full Gemini product-shoot case study.

See them in action

Litepanels publishes fixture demos and setup walkthroughs on its official YouTube channel, including a Gemini soft light overview that shows the colour and softbox behaviour on a real set.

Frequently asked questions

Should I choose Gemini or Astra IP for a studio?

Choose Gemini if colour, gels and effects are central to your work, or you want the softest, most flattering key with the widest colour temperature range. Choose Astra IP if you want maximum reliability, accurate white light and value, especially for corporate, education, streaming and multi-use rooms. Most studios end up combining the two.

How many lights do I need to start a studio?

Three fixtures cover a proper key, fill and hair or background light, which is enough for portraits, interviews and most product work. A fourth light dedicated to the background adds separation and colour. You can grow from there as your work demands.

What is the difference between the soft and hard Gemini panels?

Soft panels have a large diffused surface for a gentle wrap straight out of the box, ideal for faces and beauty. Hard panels put out a more directional, punchier beam for throw, effects and cutting through larger spaces. Many studios keep both.

Do LED studio lights save money on running costs?

Yes, in most cases. LED fixtures like the Gemini and Astra IP draw a fraction of the power of traditional tungsten or HMI lighting, which cuts both your electricity bill and the air-conditioning load from the heat they would otherwise produce. As a real example, when Plaid Turtle switched to 20 Litepanels Gemini 1x1 Hard panels they replaced more than 70 traditional fixtures and cut power draw from over 70,000 watts to about 4,000 watts. Actual savings depend on your tariff and how much you shoot, so treat it as an indicative example rather than a guarantee.
